Steel
Pickup OHMS are approximate as pickups are wound when ordered. Most of the pickups here can be altered to customers needs- including wire gauge,magnet type, color, string spacing and hook up leads.
Free shipping within the USA if yours
is an international order please email
us at sentellpickups@gmail.com for
shipping prices to your country.
LS21
LS21-Red
Pedal Steel Pick-up
12.2 k ohms
Handwound with 42 awg
10 quarter inch diameter alnico 5 magnets
Magnet polarity south to strings
3" stringspread
4" long x 1.4" wide x .6" tall
Basepate is 4" long x 1.9" wide
Mounts with 4 mounting holes through baseplate
$110.00
LS20
LS20 - Green
Pedal Steel Pick-up
11.24k ohms
10 quarter inch diameter alnico 5 magnets
Magnet polarity south to strings
3" stringspread
4.25" long x 1.5" wide x .60" tall
Mounts with two screw holes through the top
Mounting screws included
$110.00
Hi Christine, tell Jerry that I received the pickup today, have done some testing and I guess I can say this is the best pickup available for pedalsteel today !!!! Sounds just fantastic. Jerry Sentell, Thanks a lot for making great pickups! I will for shure spread the word around......!
Thanks again
arnstein
LS19
Eight String Single coil
Stringmaster style
will work in Fender 1000
7.5k ohms
42awg
Eight Alnico V slugs
Handwound / Wax potted
No claw required
$90.00 each
LS19 Set of two $170.00
Jsg Damn
after playing it all night I can't believe how much it improve the sound! It add lot of bass and the signal is stronger, the original signal sound very thin in comparison, and imagine it's already the best pedal steel tone, now it's better than that!!! I have blend pot like a stringmaster. The bridge is always at 100% and you gradually add the neck pickup. I like 50% neck pickup for E9 to keep a bright tone and 75% on the C6 neck. If I play Hawaiian music I put the neck pickup at 100% to have a very fat tone!!!
S40
Stringmaster- replacement
Fits:
Fender style String master &
Champ Deluxe 8 By Hudson Steel Guitars
42 A.W.G
7.8K OHMS
Wax potted, Alnico V slugs
black fiber board.
Handwound/ wax potted
$90.00
Set of two $170.00
Our LS19 and S40 stringmaster pickups do not fit under a cover they are built to be open faced. If you have a cover you want to use send it to us and we will build your pickup to fit.
LS15
LS-15
10 String Pedal Steel
Modeled after Emmons
11.2k ohms
42 awg
Ten Alnico V rod magnets
South
Top is 3 ply pickguard material
Two conductor hook-up wire
Wax potted
$120.00
LS10-D
S-10
Modeled after the Dekley pedal
steel
18.7K ohms
42 awg
Ten Alnico V rod magnets
Magnetic polarity south to strings
Two conductor
Vulcanized fiberboard flatwork
3/4" tall
$100.00
SM01
NC-17
1/4"deep 1 1/4" wide x 3 3/4" long
11.8 K ohms
44 awg
Scatter-Wound
Wax Potted
Two conductor leads
$85.00
LS6
NC-18
Same as the NC-17
except built to your string spread
$90.00
LS1 sc
Replacement pick-up for
Champion lap steel
7.5 K 0hms
42 AWG
Alnico 5 rods
.688" tall
Handwound
Wax potted
Pick-up comes shielded with coil tape
$105.00
LS69
Replacement pick-up for
BR-6 & BR-9 Lap Steel Guitar
4.8K ohms
Handwound with 41 awg formvar
58.9mm string spread
1/4" diameter alnico 5 slugs
Magnetic pole south to strings
Two conductor hook-up leads
Wax Potted
springs & mounting screws included
$110.00
LS9
LS9
13.1k ohms
Eight quarter inch Alnico 5 rods
Handwound with 42 awg
2 7/8" string spread
3 7/8" long x 1 1/2" wide x 3/8" deep
Wax potted
Brass flathead mounting screws included
Customized versions
of this pick-up also available
$95.00
LS10
Eight string
Will work in Fender 400
10.8k ohms
Handwound with 42 Awg
65mm string spread
100mm long x 38mm wide x 11mm high
Eight Alnico V rod magnets
Handcrafted Fiberboard flatwork
Two conductor hook-up leads
Wax potted
$95.00
I had Jerry custom wound my LS-10 to 8k ohms. It improved the clarity over the stock pickup in my Fender 1000 pedal steel. It sounds more like a Stringmaster. Ordered another wound to 7.5k for the second neck. Great quality at a great price!
Tim W.
LS2-8
Single coil pickup for Console Grande
steel guitar
5.4k ohms
Fiber board bobbin
Magnetic pole south to strings
Handwound w/ formvar for vintage tone
Eight Alnico V slugs
Two mounting screws included
$95.00
LS18
Dogear Style Eight String
Humbucker
12.4K ohms
Stingmaster string spread
Sixteen Alnico V rod magnets
Four conductor hook-up leads
Wax Potted
Standard dogear size
4-5/8" Long x 1-5/8" Wide x 7/16" Tall
$130.00
"Got the guitar a couple of hours ago.Been playing it the whole time. I
really like my other one but this one is a whole different animal. Highs
are clear and thick,lows are clear and powerful, really clean with the
splitter on. Its just WOW!!!
LS18-6
Dogear Style Six String
Humbucker
58mm Stringspread
11.1K ohms
Twelve Alnico V rod magnets
Four conductor hook-up leads
Wax Potted
Standard dogear size
4-5/8" Long x 1-5/8" Wide x 7/16" Tall
$120.00
LS5
I've have been playing my lap steel build for several days and wanted to let you know how impressed I am with the sound of the Tennessee Honey PU. All the tone and bark I envisioned when I started building the guitar.
Thanks for building me a great pickup!
Greg
Tennessee Honey
P90 Type Soapbar
w/ 58mm String spread
for Lap Steel
7.5 K ohms
Handwound with 42 awg
Two Alnico III magnets
south to strings
Two conductor hook-up leads
Wax Potted
$105.00
LS7
10 String Steel Guitar Pickup
1 7/8" wide
4 3/4" long
3/4" Tall
20 Alnico V rods
Four conductor humbucker
Handwound with 42 awg
3/8" string spacing
stringed instrument more tone
versatility
Comes pre-linked for
humcancelling
$125.00
LS17
Sidewound Blade
Humcancelling
3-7/8" Blade
EMG 2 hole mount cover
4.50" long x 1.50" wide x .895" deep
12.2K Ohms
Alnico V magnets south to strings
Four conductor hook up leads
Pick-up comes prelinked for
humcanceling
$118.00
LS14
LS-14
Sidewound Humbucker
16.4K OHMS
Alnico V
south to strings
Four conductor hook-up leads
Extra ground wire to blade
80mm long blade will
accommodate up to
69mm string spreads
P-90 soapbar cover
Mounting screws included
Handwound / Wax Potted
$118.00
